8 Channel Optical Input Card
NV-MCMC-MCS-GR764
Description
Specifically designed for digital HD Mixed insertion Matrix Switcher, it supports four channels high-speed dual-core LC fiber interface input and also supports digital 1080P HD signal. Farthest transmission distance can reach 20km. Integrated board card design. It can choose the quantity of board card at will as needed, which brings much convenience for applications and maintenance.
Featured
- 8- channel optical fiber signal input.
- The highest resolution ratio supported can reach 1080P.
- Can be applied for LC dual-core signal and multimode technology, and the farthest transmission distance can reach 20km.
- full-digital zero compression technique of high-performance signal transmission is applied.
- The biggest resolution ratio input supported: HDPC: 1920 x 1200P@60_24bit, HDTV: 1920 x l080P@60_36bit.
- Plug and play, very convenient
Specification
| Model | NV-MCMC-MCS-GR764 |
| Input | 8-channel Optical Fiber Signal (Double core and single-mode) |
| Input Connector | 8-channel LC Optical Fiber Connector |
| Transmission power | -5dB (Standard) |
| Maximum Wastage | 13dB |
| Wavelength | Multimode 850nm /Single mode: 1310 – 1620nm (Optional) |
| Multimode Fiber Standard | 50/125µm |
| Signal Mode Fiber Standard | 9/125µm |
| Bandwidth Of Port | 3.25Gbps, Full digital |
| Clock Jitter | >0.15 Tbit |
| Rise time | >0.3 Tbit (20%–80%) |
| Fulltime | >0.3 Tbit (20%–80%) |
| Farthest Output Distance | 0M3 For Multimode Fiber: Less than 500m, Single mode
Fiber: 2 – 20km |
| Specification | |
| Max power consumption | 15W |
| Product Weight | 1.0kg |
